MCI® 2020 is an organic, surface applied, migrating corrosion inhibitor designed to penetrate through cementitious materials including concrete, mortar and limestone. It migrates in both liquid and vapour (gas) phases through the pore structure, forming a protective, molecular layer on embedded reinforcement and allowing vapour diffusion. MCI® 2020 provides strong corrosion protection against carbonation, chlorides and other contaminants and will migrate independent of orientation (horizontal, vertical or overhead) up to 8 cm (3 in.) in 30 days.
Water based, non-flammable MCI® 2020 offers engineers, owners, contractors, DOTs and other government agencies a time proven, corrosion inhibiting technology that will significantly extend the service life of their reinforced concrete structures. MCI® 2020 can be applied to new concrete or used for rehabilitation and will not delay construction or increase costs. Unlike standard inorganic inhibitors it does not have to come into contact with the reinforcing steel upon application. MCI® 2020 is considered ambiodic, which means it protects both anodic and cathodic areas within a corrosion cell. It contains a synergistic blend of amino-alcohols and salts of carboxylic acids, which form a protective layer on embedded reinforcement delaying the onset of corrosion as well as reducing existing corrosion rates.
MCI® 2020 is recommended for: preventative maintenance of existing reinforced, precast, prestressed, post-tensioned, or marine concrete structures, bridges, highways, and industrial floors exposed to aggressive environments (chemicals, deicing salts, carbonation, atmospheric attack), parking garages, concrete piers, dams, offshore platforms, piles, pillars, pipes, utility poles, cooling towers and concrete potable water structures. It is also an important component of Cortec®’s High Performance Repair System™ (HPRS®).
MCI® 2020 is easily applied by spray, brush or roller and does not etch, stain, discolour or otherwise harm glass, metals or automotive paint. It does not contain calcium nitrite or wax and no removal of sound concrete is required. Its high performance is proven in both lab and field testing.
MCI® 2020 conforms to ASTM G 109, ASTM E 96, meets ANSI/NSF Standard 61 Approval for structures containing potable water and is RoHS compliant.
MCI® 2020 was chosen for renovation of the Pentagon and has won the International Concrete Repair Institute Award for the best repair project.
Corrosion of embedded reinforcing steel was causing spalling on the walls of Pentagon. Carbonation on the walls lowered the pH of the concrete causing the corrosion. The requirements included: a minimum 20 year design life, stop water absorption, reduce or stop corrosion, and maintain the appearance of the walls. The repair program consisted of 18 600 m2 (200 000 ft2) of surface hand patch repair and over 92 903 m2 (1 million ft2) treated with MCI® 2020 V/O, and a silicate based coating. MCI® 2020 V/O was chosen to protect and repair the walls based on its warranty and its fulfillment of the other specified repair design requirements. MCI® 2020 enabled Pentagon building premium repair, rehabilitation, and protection for the next 50 years.
Adapted from press release by Louise Fordham
Read the article online at: https://www.worldcement.com/product-news/11032015/extending-the-service-life-of-concrete-structures-174/
