At Hannover Messe 2015, Aucotec AG (Hall 7, stand B28) will introduce its Advanced Typical Manager for the first time. This provides greater clarity and consistency in variant management. With the new module of software platform Engineering Base (EB), the company confronts the rapidly growing complexity designers are faced with today in the sometimes-insurmountable number of variants and options available when configuring machines and plants. Aucotec will also be introducing the result of its collaboration with Siemens PLM software: the new Teamcenter interface for improved PLM integration of EB.
Advanced Typical Manager.
Function modules instead of thousands of sheets
The new Typical Manager makes use of functional engineering in order to fully exploit the undoubted savings potential in configuring. The mechatronic modules to be configured no longer consist of individual motors or sensors, but consist instead of complete functions such as gripping or heating. Thus, the configuration is located at a level higher than sheet level and is clearer and more precise as a result.
The documentation of such a function consists of a quality-tested template (typical). This contains the associated sheets, devices, cables and wires that are handled ‘as a whole’ in their functional context. This saves customers from copying a project consisting of thousands of independent single sheets, which cannot be continuously maintained. In addition, unavoidable changes that arise while constructing the plant can be incorporated via the update function without having to undo the individual customisations that were already created up to that point. As a results in time-savings as the entire project no longer has to be regenerated in the event of subsequent changes or has to be created ‘manually’ as of the change request.
Documentation at the press of a button
With the Advanced Typical Manager, options such as brakes or sensors are defined separately as circuit components in EB. The otherwise necessary variants of sheets with all possible combinations of options for one motor are thus a thing of the past. In the event of changes, one only swaps the optional circuit component instead of ‘drowning’ in variants and options. EB also stores the data as quality-tested modules for variants resulting from different dimensions or manufacturers. When selecting a particular motor, the system automatically assigns the correct item numbers to the correct components. If all functions that can be ordered are preconfigured in the EB database, the Advanced Typical Manager will provide yet another level of configuration: the documentation of the entire plant or machine at the press of a button.
Seamless PLM integration between Teamcenter® and Engineering Base
With the new interface to the PLM system Teamcenter®, which Aucotec will also be introducing live for the first time at Hannover Messe, all information about a plant, machine, or a mobile system can be securely managed throughout its entire life cycle. Thus the management and forwarding of released engineering documents is possible with access control and revision management for rapid availability of all current project data from EB. One can also easily create and update order or production lists to provide correct data at all times to every department involved. The new solution automatically synchronises the catalogue information with the article master data. This prevents multiple entries and unnecessary errors. In addition, each workflow can be customised.
The Teamcenter® interface is the result of an agreed collaboration between Aucotec and Siemens PLM Solutions in 2014. Siemens PLM Software is one of the leading providers of PLM software and services worldwide.
Adapted from press release by Louise Fordham
